X35 Monitor Air Seeder Setup
6.63
9. Drive - select the ECU drive that the Pack
Master is connected to.
a. It will be Drive 1 on the last CM-40 on
the list.
Note
These next four settings are generated from
calibrating the pack force sensor in the Seeder
Controller screen.
If a new profile is required these settings can be
recorded and re-entered rather than having to
recalibrate the pack force sensor.
10. Minimum Calibration Load
11. Maximum Calibration Load
12. Min
Calibration Value
13. Max Calibration Value
14. Drill Model - select the model for your
drill
(tillage unit) to apply the appropriate
parameters for calibrating the pack force
sensor.
15. Opener Type - select your opener type to
apply
the appropriate parameters for calibrating
the pack force sensor.
a. PHD or XTC for 3320 & 3420
b. ICD for 3720
