X35 Console General Operations
8.27
lb/US gal kg/l
8.34 1.00 Water 1.00 1.00
9.00 1.08 1.08 1.04
10.00 1.20 1.20 1.10
10.65 1.28 28-00-00 1.28 1.13
10.92 1.31 15-00-00-20 1.31 1.14
11.04 1.32 12-00-00-26 1.33 1.15
11.79 1.41 10-34-00 1.42 1.19
12.00 1.44 1.44 1.20
14.00 1.68 1.68 1.30
Figure 8.52 - Liquid Calibration Conversion Factor
liquid control conversion factors.xls
b. If using a different flow meter, find the
calibration factor on the flow meter body.
i. Ensure that the calibration factor
units match the selected volumetric
units for the tank and application rate
display.
ii. In most cases this given factor will
be for water and must be adjusted
for the fertilizer being used.
iii. Proceed to the calibration factor
conversion instructions in Step 5.
5.
Calibration Factor Conversion:
a. Determine the conversion factor for the
fertilizer being used from the table in
Figure 8.52.
b.
Multiply the flow meter calibration factor
for water by the conversion factor.
c. This new calibration factor can be entered
using Manual Entry button (Item C, refer
to Figure 8.51).
Important
It is recommended to perform a flow calibration
to ensure accurate application rates as there are
many factors that can affect the accuracy. If at
anytime during operation, accuracy is questioned,
a calibration should be completed.
