2. Mount a BH Sensor (Figure 13.13) onto ONE
of the tertiary lines from each secondary
manifold (refer to Figure 13.15).
a. Cut the tertiary line approximately 3-4"
from the secondary manifold head and
insert the BH Sensor.
i. DICKEY-john style sensors (Figure
13.13) have an arrow on them to
show
the install direction. Ensure
that the arrow points in the direction
of product flow OUT of the manifold
head.
ii. Use the clamps to secure the sensor
to the tertiary line.
b. Place a number sticker (included with kit)
on each of the BH Sensors, as they are
numbered in the layout drawings (Figures
13.16). This will assist with finding the
blocked
sensor when it is reported on your
monitor.
3. Refer to Figures 13.16. Connect the ECU
leads
from the main trunk harness into the
EM-24 ECU.
4. Install the 14 BH Sensor Adaptor harness
(3132-46) to the IN 1-14 port on the ECU.
a. Connect all of the remaining BH Sensors
to the 14 BH Sensor Adaptor harness as
shown in Figures 13.16.
b.
If there are more than 14 sensors there will
be a second harness to be installed.
i. Cap all unused connectors.
ii. Connect the different length
extensions and run to each sensor as
required.
5.
Where available, tie all of the harnesses to the
tertiary hoses with the ties that are provided
with the kit.
a. Ensure that the harnesses do not interfere
with any trips or linkages on the tillage
unit.
Refer
to Section 6.7.6.2 - Blocked Head Monitor
and Section 13.3 - X35 Blockage Monitoring for
operating
information of the Blockage Sensors.
