Topcon X35 - Page 70

X35 Monitor System Settings
4.10
Figure 4.10 - Quick Start - Change Job
4. Change Job - will prompt to select or create a
job with a Default, Custom or Entered name.
5. Configur
e Job Regions - will prompt to
assign internal boundaries to work or exclude.
6. Load
VRC Map - will prompt to
automatically load a VRC map from the
inserted thumbdrive.
7. Set
Guidance Mode - can be set to whatever
guideline type will be used.
8. Change
Guideline - prompts the user to select
or create guidelines with default, custom or
entered names.
9. Auto
Hide on Success - will hide the Quick
Start window automatically once the job
successfully started.
Figure 4.11 - Quick Start - Guideline Mode
Figure 4.12 - Quick Start - Change Guideline
