Maintenance3303−4/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
6/ 7
Turn crank 35_ after T.D.C.
Connect rope ’a’ with lifting tackle H
3
an
d
RUD-eye bolt R
3
. Tauten rope.
Connect rope ’c’ (lifting capacity 1500 kg) wi
th
lifting tackles H
1
and to RDU-eye bolt R
3
.
Tauten rope.
Remove holder 94331.
Carefully separate connecting rod fro
m
crankpin using spur-geared chain block 1
3
and lifting tackles H
1
and H
3
.
Remove lifting tackle H
1
.
The connecting rod can be removed no
w
from the engine using spur-geared cha
in
block 13 and lifting tackles H
1
.
H
I
013.037/05
c
b
H
1
H
1
94331
R
3
H
3
b
a
c
1
3
2010
Connecting Rod: Removal and Fitting
