Maintenance3303−5/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 2
⇒ Connect rope ’c’ with lifting tackle ’HZ’ and RUD-eye bolts ’RC’.
⇒ Lower bearing cover 2 towards fuel side.
⇒ Connect rope ’d’ with spur-geared chain block 7 and RUD-eye bolts ’RC’ and
subsequently remove the bearing cover from the crankcase.
D Fitting of the bearing cover is carried out analogously to the removal but in re-
verse sequence.
C D
013.039/05
7
HZ
2
c
d
c
RC
emoval of Bearing Cover to Top End Bearing
2010
