Maintenance3326−2/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 7
2. Removal of crosshead pin
⇒ Fit wire rope sling 94666 onto column lug
3.
⇒ Fasten lifting plate 94324 with their shackle
s
to crosshead pin 2 with nuts 8 (Fig. ’E’) of th
e
screwed connection for the piston rod foot
.
⇒ Connect wire rope sling with lifting tackle ’H
Z’
(lifting capacity 1500 kg) and to one of th
e
shackles at the lifting plate.
A
3
1
94666
94324
2
94142
013.237/05
2
H
2
RC
4
RC
H
1
013.238/05
⇒ Screw RUD-eye bolts ’RC’ into the connec
t-
ing rod head 4 on both sides.
⇒ Connect lifting tackles H
1
and H
2
(lifting c
a-
pacity 1500 kg each) to RUD-eye bolts ’RC
’
and tauten them.
⇒ Lift up crosshead pin 2 as far as possible.
B
HZ
2010
Removal and Fitting of a Crosshead Pin
