Wartsila RT-flex50-D User Manual

Maintenance6708−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
4/ 10
018.323/09
D
x
H
2
H
3
94667d
⇒ Using manual ratchet H
3
(WLL 800 kg) pull out water separator 3 from the re-
ceiver by approx. ’x’ = 1030 mm, i.e. slightly more than half of the water sepa-
rator. Continuously follow with spur-geared chain block H
2
adjusting the
height accordingly till the wire rope of limiter 94667d is tensioned.
018.324/09
E
H
1
94667b
H
3
⇒ Dismantle limiter 94667d with its wire rope.
⇒ Remove lifting tool 94667b, refit it in the middle of the water separator and
hook spur-geared chain block H
1
in the mentioned tool.
2010
R
emoval and Fitting of Water Separator
