Maintenance
0352−1/A1
RT-flex50-D
Wärtsilä Switzerland Ltd
3/ 16
Group Description Thread Tightening values Lubricant
1
[bar]
2
[Nm]
3
[_(; mm]
4103−3
Gear wheel on crankshaft, nut for
waisted bolt to flanged connection
(secured with LOCTITE No. 262)
27
M24x2 (800)
70_
see details in
4103−3
Gear wheel (2-part) on crankshaft
(spare wheel), waisted stud
28
M30x2
Elongation 1.20± 0.06mm
see details in
4103−3
5
5552−2
Bearing cover − supply unit, waisted
screw
29
M30 1450
Oil
5552−3
Camshaft − gear wheel, head screw
30
M16 200
Oil
5556−1
Fuel pump cover − upper housing,
screw
31
M16 115
Never-Seez
NSBT-8
Fuel pump − supply unit, screw
32
M24 600
Oil
Fuel pump, bush to lower housing
33
M80x2 200
see details in
5556−1
5562 *
Non-return valve, transition nipple −
fuel rail
34
M36x2 450
Never-Seez
NSBT-8
*
Non-return valve, nipple − transition
nipple
35
M36x2 400
Never-Seez
NSBT-8
*
Non-return valve, screw plug −
nipple
36
M27x2 300
Never-Seez
NSBT-8
*
Transition nipple
37
M27x2 300
Never-Seez
NSBT-8
*
Pressure transmitter
38
M14x1.5 25
Never-Seez
NSBT-8
*
Screwed connection to end cover −
fuel rail
39
M16 180
Never-Seez
NSBT-8
*
Screwed connection to intermediate
piece − fuel rail
40
M16 190
Never-Seez
NSBT-8
5562−1
Fuel pressure control valve − inter-
mediate piece, screwed connection
41
M16 190
Never-Seez
NSBT-8
1 When using other hydraulic jacks, required pressure in bar must be calculated in relation to effective jack piston surface!
Conversion factor: 1 Nm = 0.102 mkp 1 bar = 1.02 kp/cm
2
2 Tightening torque
3 Tightening angle or elongation
Numbers in
f refer to illustrations on pages 7 to 16.
Values in parentheses (...) are for information only, to be used for comparison.
Screwed connections must be tightened in accordance with values not in parentheses.
Respective lubricant has to be applied to threads and seating surfaces, if no other instructions are mentioned.
Bostik Findley Inc. (USA) is manufacturer of Never-Seez NSBT-8.
* Tightening procedure not mentioned in this Manual.
2010
T
ightening Values of Important Screwed Connections
