Wartsila RT-flex50-D - Page 96

Maintenance0803−1/A1 RT-flex50-D
Wärtsilä Switzerland Ltd
2/ 2
Longitudinal section:
WCH00126
2303−1
1132−2
2722−1
4325−1
2124−1 to
2124−3
4103−3
2751−1 to
2751−4
3403−1 to
3403−4
2708−1 to
2708−3
3146−1
9223−1
3303−1 to
3303−5
3130−1
3425−1
1903−1
3130−2
1224−1
1132−1
2138−1
1203−1
E
ngine Cross Section and Longitudinal Section
2010 / Pulse Jet
