3.1 Rules for Describing Messages
The following table shows the rules for describing messages.
Table 3.1-1 Rules for Describing Messages
Symbols Usage
<>
Parameters in triangle brackets are input by
the programmer.
[]
Parameters in square brackets can be omitted.
|
Select one out of multiple choices.
In the case of A|B|C|D, select one from A, B,
C, or D.
{}
Group the choices.
In the case of A|B ({C|D}), select one from A, B
(C) or B (D)
<binary_data>
This string is in binary data format.
<file_name>
Character string within 32 characters enclosed
by single quotes (')
\,/,:,*,?,",<,>,|
cannot be used.
Example
'
Sample_LD(201)
'
<numeric>
This is a string of numeric code.
Example 0,1.2E-6,2.35
<string>
This is a character string data.
<switch>
This is a specific selection of message.
Example 100KHZ, LEFT
<trace>
Select one from A,B,C,D,E,F,G,H,I,J.
<trace_name>
Select one from
A,B,C,D,E,F,G,H,I,J,TRA,TRB,TRC,TRD,TRE,T
RF.
<unit_h>
Select the frequency unit from below.
THZ: THz (10
12
Hz)
GHZ: GHz (10
9
Hz)
MHZ: MHz (10
6
Hz)
KHZ: kHz (10
3
Hz)
HZ: Hz
<unit_m>
Select the frequency unit from below.
M: mm (10
–3
m)
UM:
µ
m (10
–6
m)
NM: nm (10
–9
m)
PM: pm (10
–12
m)
A: am (10
–18
m)
<user_drive>
Select one from E,F,G,H,I,J,K,L,M,N,O,P,
Q,R,S,T,U,V,W,X,Y,Z.
