Chapter 3 Message Details
3-6
Table 3.2.2-2 Correspondence Between F2 Level Scale Key and Message
f1-f8 Key Name
Command
Query
Log (/div)
:DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:PDIVision
:DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:PDIVision?
Ref Level
:DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:RLEVel
:DISPlay[:WINDow[1]]:TRACe:Y[1|2][:SCALe]:RLEVel?
Peak->RefLevel
:CALCulate:MARKer:MAXimum:SRLevel
Linear Level
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:BLEVel
:DISPlay[:WINDow]:TRACe:Y1[:SCALe]:BLEVel?
Opt.Att
On/Off
:SENSe:ATT[:STATe]
:SENSe:ATT[:STATe]?
Table 3.2.2-3 Correspondence Between F3 Res/VBW/Avg Key and Message
f1-f8 Key Name
Command
Query
Res
[:SENSe]:BANDwidth|BWIDth[:RESolution]
[:SENSe]:BANDwidth|BWIDth[:RESolution]?
VBW
[:SENSe]:BANDwidth|BWIDth:VIDeo
[:SENSe]:BANDwidth|BWIDth:VIDeo?
Point
Average
:SENSe:AVERage:COUNt
:SENSe:AVERage:COUNt?
Sweep
Average
:CALCulate[1|2|3|4|5|6]:AVERage:COUNt
:TRACe:ATTRibute:RAVG[:<trace_name>]
:CALCulate[1|2|3|4|5|6]:AVERage:COUNt?
:TRACe:ATTRibute:RAVG[:<trace_name>]?
Smooth
:SENSe:SETTing:SMOoth
:SENSe:SETTing:SMOoth?
Sampling
Points
[:SENSe]:SWEep:POINts
:TRACe:POINts
[:SENSe]:SWEep:POINts?
:TRACe[:DATA]:SNUMber?
:TRACe:POINts?
Act-Res
On/Off
:CALibration:ACTRes
:CALibration:ACTRes?
