1‑305
Chapter 1 Troubleshooting
Version 1 2006.11.21
C
Checking the BELT CRU
installation
Reseat the BELT CRU.
No
Yes
Checking the Toner
Cartridges installation
Reseat the all Toner
Cartridges.
No
Yes
Checking the DRIVE ASSY
MAIN installation
Reseat the DRIVE ASSY
MAIN. (Removal 36/
Replcement 10)
END
No
Yes
END
D
END
Does the noise arise
from the printer?
Does the noise arise
from the printer?
Does the noise arise
from the printer?
Checking the DRIVE ASSY
PH installation
Reseat the DRIVE ASSY
PH. (Removal 15/
Replacement 31)
No
Yes
END
Does the noise arise
from the printer?
