Checking the Main Motor
No
Yes
D
Try replacing the DRIVE
ASSY MAIN. (Removal
36/Replcement 10)
Does the noise
arise from the printer?
Checked by [Digital
Output]-[DO-0] in [IOT
Diagnosis].
Checking the Deve Motor.
No
Yes
Try replacing the DRIVE
ASSY MAIN. (Removal
36/Replcement 10)
Does the noise
arise from the printer?
Checked by [Digital
Output]-[DO-f] in [IOT
Diagnosis].
Checking the Sub Motor
No
Yes
Try replacing the DRIVE
ASSY MAIN. (Removal
36/Replcement 10)
Does the noise
arise from the printer?
Checked by [Digital
Output]-[DO-5] in [IOT
Diagnosis].
