Configuring Routing 575
Figure 9-44. Virtual Router Secondary Address
3. In the Secondary Address field, select Create to add a new secondary IP address, or select an existing
secondary IP address to modify.
4. In the IP Address field, enter the secondary IP address.
5. Click Apply Changes .
Configuring VRRP Interface Tracking
1. Open the VRRP Router Configuration page.
2. Click Track Interface .
The VRRP
Interface Tracking Configuration page displays. From this page, you can add a new
interface to track or remove a tracked interface.
Figure 9-45. VRRP Interface Tracking Configuration
3. Click Add .
The page refreshes, and the configuration fields appear.
