4.23 Sensor Module-To-Controller Cable Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 68 Isolette® Infant Incubator (Model C2000) Service Manual
CAUTION:
Use caution when lowering the shell assembly in place on the shell
bottom. Ensure that no cables are pinched and that the extrusion
bumper fits properly. Failure to do so could result in equipment
damage.
4. Stand at the same end of the shell assembly (C) as the controller
assembly (E), and perform the following (see figure 4-29 on page
4-66):
a. Connect the corrugated hose (H) to the check valve assembly
(I).
b. Carefully lower the shell assembly (C) in place on the shell
bottom (B).
c. Ensure that no cables are pinched between the shell assembly
(C) and the shell bottom (B).
d. Ensure that the extrusion bumper (D) fits properly between the
shell assembly (C) and the shell bottom (B).
CAUTION:
Always replace Nylok®
1
screws; do not reuse them. Equipment
damage could occur.
5. Install the four new Nylok® screws (A) to secure the shell bottom (B)
to the shell assembly (C).
6. If the unit is equipped with an oxygen system, install it (refer to
procedure 7.2 on page 7-8).
7. If the unit is equipped with a humidity system, install it (refer to
procedure 7.3 on page 7-15).
8. Install the impeller assembly (refer to procedure 4.8 on page 4-22).
9. Install the mattress, the mattress tray, and the x-ray tray on the unit
(refer to procedure 4.7 on page 4-20).
10.Install the hood assembly on the unit (refer to procedure 4.5 on page
4-14).
1. Nylok® is a registered trademark of Nylok Fastener Corporation.
