Dräger Isolette C2000 Service Manual

High Front Access Hood Assembly with Two Access Doors and Left & Right Iris Ports (P/N 83 200 71-
R) (Series 00 Model)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 19
5
Table 5-4. High Front Access Hood Assembly with Two Access Doors
and Left & Right Iris Ports (P/N 83 200 71-R) (Series 00 Model)
Item Number Part Number Quantity Description
1 83 900 60 1 Replacement kit, front access, iris
ports left and right, pawl
2 83 200 15 2 Keeper, access panel latch
3 83 200 10 1 Hinge, hood/access panel, right front
4 83 200 11 1 Hinge, hood/access panel, left front
5 83 200 16 1 Hinge, hood, left, rear
6 83 200 17 1 Hinge, hood, right, rear
7 83 300 05 2 Door, access
8 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
9 83 300 07 2 Gasket, access door
10 83 300 08 4 Pivot hinge, access door
11 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.03" wide, 0.365" long
12 83 900 09 2 Replacement kit, access door latch
13 83 300 15 2 Latch mount, access door
14 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
15 83 200 20 6 Grommet, access
16 68 120 76 2 Ring assembly, iris port, large flange
17 68 120 32 2 Ring, retaining, iris port, clear
18 68 120 57 2 Sleeve, iris port, disposable, soft
19 83 001 10 1 Heat shield, access panel, high
20 99 088 67 4 Screw, self-tapping, #8 x 3/8", pan,
phillips, steel, zinc-plated, 48-2
21 99 023 51 2 Screw, #6-32 x 3/8", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
22 99 023 64 8 Screw, #6-32 x 7/16", truss, phillips,
stainless steel, Nylok®
23 99 024 19 6 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
