High Front Access Hood Assembly with Two Access Doors and Left & Right Iris Ports (P/N 83 200 71-
R) (Series 00 Model)
Chapter 5: Parts List
Page 5 - 20 Isolette® Infant Incubator (Model C2000) Service Manual
Item Number Part Number Quantity Description
24 99 042 66 4 Screw, #10-32 x 5/8", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
25 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
26 83 300 09 2 Latch, heat shield
27 83 300 10 2 Hinge, heat shield
28 99 105 20 2 Nut, acorn, #6-32, aluminum
29 83 200 45 2 Slide assembly, sensor module
30 83 200 42 1 Plate, cover, no calibration fixture
31 68 232 24 1 Standoff, #6-32 inside diameter, 0.38"
outside diameter, 0.44" long, acety-
lene
32 99 024 18 1 Screw, #6-32 x 9/16", truss, phillips,
stainless steel
33 99 105 02 4 Nut, hex, #6-32, stainless steel
34 99 024 52 4 Screw, #6-32 x 5/8", pan, phillips,
stainless steel, Nylok®
35 67 502 51 2 Base, screw, ¼"-20, pan
36 83 100 45 2 Plate, hinge and magnet
37 83 300 33 1 Magnet, ¼" square, 1.00" long, alnico
38 83 300 04 1 Plate, backup, hinge, heat shield
39 83 200 18 2 Plate, backup, hinge, left front and
right rear
40 83 200 19 2 Plate, backup, hinge, left rear and
right front
41 83 300 13 1 Bracket, heat shield, rear
To Next Page
