High Front Access Hood Assembly with Two Access Doors and Left & Right Iris Ports (P/N 83 200 78)
(Series 01 Model)
Chapter 5: Parts List
Isolette® Infant Incubator (Model C2000) Service Manual Page 5 - 23
5
Table 5-5. High Front Access Hood Assembly with Two Access Doors
and Left & Right Iris Ports (P/N 83 200 78) (Series 01 Model Only)
Item Number Part Number Quantity Description
1 83 200 61-R 1 Hood, high, front access, two access
doors, rear, iris ports left and right
2 83 200 10 1 Hinge, hood/access panel, right front
3 83 200 11 1 Hinge, hood/access panel, left front
4 83 200 12 1 Hinge, hood/access panel, left rear
5 83 200 13 1 Hinge, hood/access panel, right rear
6 83 300 05 2 Door, access
7 83 300 11 1 Access door cuff, disposable,
replacement, carton of 100
8 83 300 07 2 Gasket, access door
9 83 300 08 4 Pivot hinge, access door
10 68 510 10 2 Spring, torsion, 0.27" outside diame-
ter, 0.03" wide, 0.365" long
11 83 900 09 2 Replacement kit, access door latch
12 83 300 15 2 Latch mount, access door
13 83 200 20 6 Grommet, access
14 68 120 76 2 Ring assembly, iris port, large flange
15 68 120 32 2 Ring, retaining, iris port, clear
16 68 120 57 2 Sleeve, iris port, disposable, soft
17 83 001 11-R 1 Replacement heat shield, access
panel, pawl
18 81 020 20 2 Clamp, cable, spring type, nylon,
0.38" inside diameter
19 99 088 67 4 Screw, self-tapping, #8 x 3/8", pan,
phillips, steel, zinc-plated, 48-2
20 99 023 51 2 Screw, #6-32 x 3/8", truss, phillips,
stainless steel, Nylok®
a
a. Nylok® is a registered trademark of Nylok Fastener Corporation.
21 99 023 64 8 Screw, #6-32 x 7/16", truss, phillips,
stainless steel, Nylok®
22 99 024 19 8 Screw, #6-32 x 9/16", truss, phillips,
stainless steel, Nylok®
