High Front Access Hood Assembly with Two Access Doors and Left & Right Iris Ports (P/N 83 200 78)
(Series 01 Model)
Chapter 5: Parts List
Page 5 - 24 Isolette® Infant Incubator (Model C2000) Service Manual
Item Number Part Number Quantity Description
23 99 042 66 4 Screw, #10-32 x 5/8", truss, phillips,
stainless steel, Nylok®
a
24 99 042 92 8 Screw, #10-32 x ¾", truss, phillips,
stainless steel, Nylok®, step bolt
25 83 300 09 2 Latch, heat shield
26 83 300 10 2 Hinge, heat shield
27 99 105 20 2 Nut, acorn, #6-32, aluminum
28 83 200 45 2 Slide assembly, sensor module
29 68 232 24 1 Standoff, #6-32 inside diameter, 0.38"
outside diameter, 0.44" long, acety-
lene
30 99 024 18 1 Screw, #6-32 x 9/16", truss, phillips,
stainless steel
31 99 105 02 4 Nut, hex, #6-32, stainless steel
32 83 300 36 1 Hinge, access panel, right rear
33 83 300 35 1 Hinge, access panel, left rear
34 99 024 52 4 Screw, #6-32 x 5/8", pan, phillips,
stainless steel, Nylok®
35 83 300 33 1 Magnet, ¼" square, 1.00" long, alnico
36 83 300 04 1 Plate, backup, hinge, heat shield
37 83 200 18 2 Plate, backup, hinge, left front and
right rear
38 83 200 19 2 Plate, backup, hinge, left rear and
right front
39 83 300 13 1 Bracket, heat shield, rear
40 67 502 51 2 Base, screw, ¼"-20, pan
41 83 300 56 2 Spacer, #6-32 inside diameter, 0.31"
outside diameter, 0.38" long, acety-
lene
42 99 023 58 2 Screw, #6-32 x 7/16", flat, phillips,
stainless steel
43 83 200 95 1 Plate, cover, slide fixture
44 83 200 97 1 Washer, curved spring, module—
slide-lock
To Next Page
