ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 3 - System Setup 3-113
PRELIMINARY
The Local Area Connection Properties dialog box opens.
8.) Select Internet Protocol (TCP/IP).
9.) Click the Properties button.
The Internet Protocol (TCP/IP) Properties dialog box opens.
10.)Activate the Use the following IP address check box.
11.)Type in the Vivid S5 N or Vivid S6 N IP address 10.0.0.1.
Note: The IP must be different from the IP address used for network computer.
12.)Type in the Subnet mask 255.255.255.0.
Note: The Subnet mask should be the same for both the network computer and the Vivid S5 N or
Vivid S6 N.
13.)Click OK
14.)Press the Config button on the control panel to close all windows and return to the regular scanning
mode.
Figure 3-131 Local Area Connection Properties
Figure 3-132 Internet Protocol (TCP/IP) Properties
