7-2-4-3-6 Battery Parameters Test
The Battery Parameters Test is used to check the battery status with regard to the following:
• Battery capacity
• Charging voltage being supplied to the battery (or the voltage being supplied by the battery)
• Source of the power being provided to the system (i.e. external power via the AC/DC or via the
battery [indicating the battery is either being charged or discharged]).
For test procedure instructions, see 7-5-1-6 "Battery Parameters Test" on page 7-108.
7-2-4-3-7 Tx Voltages Test
The TX Voltages Test is used to test the transmit part of the power supply to make sure that the
Tx voltage is within expected values.
For test procedure instructions, see 7-5-1-7 "Tx Voltages Test" on page 7-110.
7-2-4-4 BEP Tests
The BEP Tests are performed to check of the various Back End hardware components, as outlined
below. The procedures are described in detail in the Section 7-6 "Performing Back End Diagnostics on
the System" on page 7-113.
