3-7-5 Setup Connection to HL7 Server in a Network
3-7-5-1 Introduction
The procedures below describe how to set up the Vivid S5 N or Vivid S6 N workstation so it can connect
to the Hospital Information System (HIS), via the Vivid HL7 Gateway. By connecting to the HIS,
demographic information (i.e. Patient ID, Name, Gender, etc.) can be retrieved from the HIS, reducing
“double-work” and typing errors. Patient Reports can be sent back to the HIS for storage, together with
the rest of the Patient records.
3-7-5-2 Preparations
1.) Before you can set up the HL 7 Communication, you need to collect some information:
- The IP address of the Vivid HL7 Gateway
- Port Number used by the Vivid HL7 Gateway (Default port: 3320)
Typically, source for this information is the Mitra support personnel.
The ‘Worksheet for DICOM Network Information” on page 2-12 can be used for gathering this
information.
2.) Provide the computer name of each EchoPAC PC Workstation and Vivid S5 N or Vivid S6 N being
configured to the Mitra support personnel.
3-7-5-3 Configuration of Modality Worklist Services
Identify Dataflow to be Used
1.) Identify which dataflow is to be used at the site. If the DICOM Modality Worklist will be used, then
the dataflow must include a Worklist service.
2.) On the Connectivity screen, select the Dataflow tab.
3.) From the pull-down menu, select the name of the site's dataflow.
4.) In the Services section, locate the Worklist service.
5.) Record the service's name and destination device.
Configure the DICOM Worklist Service
1.) Select the Services tab.
2.) Select the Worklist destination device from the pull down menu.
3.) Enter the IP address of the Vivid HL7 Gateway.
4.) Enter a descriptive name in the Name field.
(Example: Vivid HL7 Gateway. The use of this field is optional).
5.) Enter AE Title. Use the Computer Name for the unit you are configuring.
6.) Enter Port Number. (Port 3320 is the default, but Mitra may have provided another port number).
7.) Set Time-out to 90.
8.) Leave the rest of the fields unchanged.
