ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
Chapter 5 - Components and Function (Theory) 5-49
PRELIMINARY
5-7-2-12 Monitor Connectors
5-7-2-13 Display Unit
The display monitor is a 15" (Vivid S5 N) or 17" inch (Vivid S6 N) LCD.
In order to optimize the display settings, a light-sensing device located on the keyboard is used for
measuring the ambient light. This data is processed by the main CPU which adapts the display setting,
accordingly.
Figure 5-38 Monitor Connectors
DVI
Power
