Chapter 4 - Functional Checks 4-33
PRELIMINARY
4-3-2 Peripherals
4-3-2-1 B/W and Color Printer Test
NOTE: If the printer is not currently connected to the system, refer to ‘Sony UP-D897 B/W Video Printer” on
page 3-59, or ‘Sony UP-D25MD Color Video Printer” on page 3-64 for configuration instructions, as
applicable.
4-3-2-2 Color Printer Test
NOTE: If the printer is not currently connected to the system, refer to ‘Connecting Printers” on page 3-27 for
configuration instructions.
Table 4-14 B/W and Color Printer Test
Step Task Expected Result(s)
1
Scan a phantom or suitable interface in 2D-Mode.
2
Press the Freeze button.
The image scanning stops with the latest picture frozen
on the screen.
3
Press the Print button.
Evaluate the print quality. Adjust the brightness and/or
contrast of the B/W printer, if required. The image
displayed on the screen is printed on the B/W or color
printer, depending upon the key assignment
configuration (refer to
1
Scan a blood vessel in 2D-Mode or a phantom
simulating a similar CFM effect, then activate CFM to
see color.
2
Press the Freeze button.
3
Press the P1 button.
Evaluate the color print quality. Adjust the brightness
and/or contrast of the Color printer, if required.
Table 4-15 Color Printer Test
Step Task Expected Result(s)
1
Scan blood vessels in 2D-Mode or a phantom simulating
a similar CFM effect, then activate CFM to see color.
2
Press the Freeze button.
3
Press the P2 button.
Evaluate the color print quality. Adjust the brightness
and/or contrast of the Color printer, if required.
