ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
7-114 Section 7-6 - Performing Back End Diagnostics on the System
PRELIMINARY
7-6-1 Accessing the Back End Diagnostic Test Options (cont’d)
7-6-1-1 PC Doctor
NOTE: For a complete description of all PC Doctor tests, refer to the information in 7-2-4-4-1 "PC Doctor" on
page 7-17.
This procedures in this section are divided into two groups. Refer to the relevant procedure, as follows:
• Automatic Tests
- 7-6-1-1-1 "Full Back End Test w/o Hard Disk Scan" on page 7-114 - see below
- 7-6-1-1-2 "Full PC Doctor Test (50 min)" on page 7-117
- 7-6-1-1-3 "CPU Tests" on page 7-119
- 7-6-1-1-4 "HD Test" on page 7-122
- 7-6-1-1-5 "Memory Test" on page 7-124
- 7-6-1-1-6 "Video Test" on page 7-126
- 7-6-1-1-7 "PCI Test" on page 7-128
- 7-6-1-1-8 "Network Test" on page 7-130
7-6-1-1-1 Full Back End Test w/o Hard Disk Scan
NOTE: For a description of this test, refer to - "Full Back End Test without Hard Disk" on page 7-17.
1.) In the Diagnostic Test window, trackball to Full Back End Test w/o Hard Disk Scan in the list of PC
Doctor tests available for selection from the Diagnostic Test Tree (see Figure 7-77 "Full Back End
Test w/o Hard Disk Scan" on page 7-115) and press Set. The Test name is displayed under Execute;
the relevant system components to be tested are highlighted light blue in the Schematic View (BEP,
Peripherals, Keyboard), as shown below:
