3-112 Section 3-4 - Preparing for Installation
PRELIMINARY
3-7-3-6-1 Configuring the Repository Remote Path
NOTE: It is possible to configure an additional user name and password for all remote paths. These settings
are only used if the system fails to log on the default user and password.
• Under Configurable Remote Path User (refer to Figure 3-129), type the desired user name and
password, as configured on the destination PC.
(This is the password usually assigned by the local IT person).
3-7-3-7 Configuring the Vivid S5 N or Vivid S6 N and Network PC for a Peer-to-Peer Connection
NOTE: The following steps are performed on the Vivid S5 N or Vivid S6 N scanner.
The instruction Select = trackball to the specific item and press the Set button on the control panel.
1.) On the control panel, press the Config button.
2.) From the System Configuration window, click the Connectivity tab at the bottom of the window.
The Connectivity dialog box opens.
3.) Select the TCPIP Tab.
4.) Trackball to the Advanced tab and press the Set button on the control panel.
5.) Select the Local Area Connection, as shown in Figure 3-130.
6.) Press the Menu button on the control panel.
7.) From the drop-down menu, select Properties.
Figure 3-130 Connectivity Dialog Box - TCPIP Advanced Tab
