8-166 Section 8-6 - Lower Section Components Replacement Procedures
PRELIMINARY
8-6-11 Fans and Fan Board Replacement Procedure (cont’d)
8-6-11-5 Fan and Fan Board Installation Procedure
NOTE: When performing the following installation procedure steps, it may be helpful to review the movie clip
previously referenced in the Fan and Fan Board Removal Procedure.
1) Place the replacement Fan (with cable attached) close to the cage assembly, then route the fan
cable (with connector attached) backwards through the rectangular-shaped hole - refer to
Figure 8-207 on page 8-165.
2) Re-connect the fan cable to the connector on the Fan Control Board.
3) Using both hands, carefully mount the replacement Fan into position on the cage assembly, taking
care to align each of the holes with the four mounting pins. Make sure the four shock absorbers are
properly seated - refer to Figure 8-206 on page 8-165.
4.) Return and fasten the four Phillips screws (previously removed) to secure the Fan Board in position
on the cage assembly, as shown in Figure 8-205 on page 8-164.
5) Return the cabinet cage assembly to the system, reconnect the cables (previously disconnected),
close the cabinet cage door and fasten securely with the two latches.
Refer to the 8-6-1-4 "Cabinet Cage Assembly Closing and Installation Procedure" on page 8-114.
6) Return the front cover, as described in the 8-2-6-4 "Front Cover Installation Procedure" on page 8-
19.
7) Return the left and right side covers, as described in the 8-2-3-4 "Left Side Cover Installation
Procedure" on page 8-7 and 8-2-2-4 "Right Side Cover Installation Procedure" on page 8-5.
8.) Turn ON power to the system.
9.) Proceed to perform the following functionality tests:
- 10-6-4 "Grounding Continuity" on page 10-23
- 10-6-5 "Chassis Current Leakage Test" on page 10-24
- 7-2-4-3-3 "Temperatures Test" on page 7-15
- 7-2-4-3-4 "Fans Speed Test" on page 7-15
- 7-2-4-3-5 "Fans Speed Setting Test" on page 7-15.
