10-4-4-2 Air Filter Cleaning
Regular cleaning of the Vivid S5 N or Vivid S6 N scanner’s air filter will ensure that the filter does not
become clogged - this would otherwise cause the system to overheat and reduce system performance
and reliability.
NOTE: It is recommended that the air filter cleaning procedure is performed once every 3 months (quarterly).
However, the required frequency for air filter cleaning will vary in accordance with environmental
conditions.
NOTE: For convenience (or if the air filter is excessively dirty), replacement filters are available. Refer
to Chapter 9 - Renewal Parts for the air filter replacement part number.
Table 10-8 Air Filter Cleaning
Step Item Description
1
Air Filter
Remove the left side cover from the system, as described in “Left Side Cover Removal
Procedure” on page 8-6.
Remove the air filter from the cover, as shown in Figure 8-6 on page 8-7.
Clean the air filter as follows: shake it in an area away from the system, wash with a mild
soapy solution, rinse, and air dry.
2
Air Filter
Install the clean air filter.
Refer to the “Air Filter Replacement Procedure” on page 8-7 for air filter installation
instructions.
