ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
2-2 Section 2-2 - Console Requirements
PRELIMINARY
Section 2-2
Console Requirements
2-2-1 Unit Environmental Requirements
NOTE: The Vivid™ S5 N and Vivid™ S6 N system may be operated at an altitude of up to 3000 meters
(9842 ft)
NOTE: After a long period of storage, or after transportation of the system with the monitor in the folded-down
position, it is highly recommended to place the monitor in the upright position - and to leave it in this
position for a period of longer than 1 hour before use. This will enable it to properly adjust to the
environmental conditions.
2-2-2 Cooling Requirements
The cooling requirement for the Vivid S5 N or Vivid S6 N ultrasound unit environment is 3500 BTU/hr.
This figure does not include the cooling required for lights, people, or other equipment in the room.
NOTE: Each person in the room places an additional 300 BTU/hr demand on the environmental
cooling.
2-2-3 Lighting Requirements
For system installation, updates and repairs, bright lighting is required. However, operator and patient
comfort may be optimized if the room lighting is subdued and indirect when a scan is being performed.
Therefore, a combination lighting system (dim/bright) is recommended. Keep in mind that monitor
lighting can be adjusted automatically on the Vivid S6 N if this option is used.
Table 2-2 Environmental Requirements
Requirement Temperature
Relative Humidity
(non-condensing)
Air Pressure
Operational
10 — 40
o
C (50 — 104
o
F)
30 — 85%
700 — 1060 hPa
Storage
-20 — 60
o
C (-4 — 140
o
F)
30 — 70%
700 — 1060 hPa
Transport
-20 — 60
o
C (-4 — 140
o
F)
30 — 70%
700 — 1060 hPa
If the system has been in storage or has been transported, please see the acclimation
requirements before powering
ON and/or using the system. 3-2-2 "Installation Warnings" on
page 3-2.
