ART NUMBER FN091065, REVISION 2 VS5 N AND VS6 N SERVICE MANUAL
8-202 Section 8-7 - Mechanical Components Replacement Procedures
PRELIMINARY
shown in Figure 8-254.
7.) Applying Loctite, insert the first locking screw previously removed and screw it in until it just touches
the supporting pin.
8.) Applying Loctite, return the second screw and tighten firmly - both the screws will now be locked
against the supporting pin.
9.) Return the Lower Arm as described in the “Lower Arm Installation Procedure” on page 8-196.
10) Return the Keyboard Assembly as described in the “Keyboard Assembly Installation Procedure” on
page 8-42.
11) Return the monitor, as described in the “Monitor Installation Procedure” on page 8-29.
12.)Turn ON power to the system.
13.)Check for proper up/down and side-to-side movement of the operator panel and monitor, as
described in “Mechanical Functional Tests” on page 4-35.
14.)Proceed to perform the following functionality tests:
- “Arm Movement Test” on page 4-35
- “Grounding Continuity” on page 10-23
- “Chassis Current Leakage Test” on page 10-24
