GD32VF103 User Manual

141

Table 9-4. DMA1 requests for each channel

Peripheral

Channel 0

Channel 1

Channel 2

Channel 3

Channel 4

TIMER4

TIMER4_CH3

TIMER4_TG

TIMER4_CH2

TIMER4_UP

●

TIMER4_CH1

TIMER4_CH0

TIMER5

●

●

TIMER5_UP

●

●

TIMER6

●

●

●

TIMER6_UP

●

DAC

●

●

DAC_CH0

DAC_CH1

●

SPI/I2S

SPI2/I2S2_RX

SPI2/I2S2_TX

●

●

●

USART

●

●

UART3_RX

●

UART3_TX
