Controller teaming
Creating a team
8-8
2. Select the Controller teaming checkbox.
3. Under Connectivity, set Communicate using to LAN port.
4. Select the Team manager checkbox, and configure the following settings under it:
Set Team name to a name that identifies the team. This example uses 1st Floor. The
team name provides a convenient way to identify a team.
Set Team IP address to the virtual IP address that will be used to provide access to
the team manager. This example uses the address 192.168.1.99.
Set Mask to 255.255.255.0.
Note: If the Team IP address is on the same subnet as the physical address assigned
to the selected Interface, then you must set Mask to match the IP mask set on the
physical interface. This applies even if the physical interface is set to act as a DHCP
client.
Set Interface to LAN port. This makes the Team IP address available on the LAN
port.
5. Select Save.
6. Controller 2 and 3 will now attempt to discover the manager. Monitor the Summary box
until you see two Unauthorized controllers in the list.
Indicates that the manager is synchronized.
Shows that two new APs have been discovered.
Indicates that manager and the two new APs were
detected.
Indicates that the manager is configured.
