2
BRIDGE MODE APPLICATION
2-4
1. Operation in the Multicast mode (continued)
3. Operation
• Radio A1 and B1 can normally communicate as if they are directly communicating in the simplex mode.
• All radios in the area must have same setting.
Area AArea B
An example of Multicast mode
Radio A
Radio A1 Radio B1
VE-PG3
(192.168.0.3)
VE-PG3
(192.168.0.2)
[TRX1]
[LAN][LAN]
[TRX1]
Radio B
