3
CONVERTER MODE APPLICATION
3-22
Menu Item Setting Screen Setting Item Item Name Value
Operating Mode Operating Mode Operating Mode Operating Mode Converter
EXT I/O Port Mode EXT I/O Port Mode Separate
V/RoIP IP Line SIP Server IP Phone Number 32 (Extension Number set in the VE-PG3 in area B)
SIP Server Address 192.168.0.3 (IP address set in the VE-PG3 in area B)
SIP Service Domain
192.168.0.3 (Extension Domain set in the VE-PG3 in area B)
User ID 32 (Extension Number set in the VE-PG3 in area B)
Password (Password set in the VE-PG3 in area B)
List of SIP Server Entries Connection Status Connection successful
Extension
Connect
Extension Connect
Extension Extension Number 301
(TRX1) Port Type Transceiver 1 (TRX1)
(EXT1) Extension Number 302
Port Type EXT I/O 1 (EXT1)
Incoming Call
V/RoIP Incoming Call Setting
Receive Port 32:302 (EXT1)
Port Settings
Transceiver 1 (TRX1)
Transceiver Model: Transceiver Model IC-F5060/F6060 (default)
EXT Input 1 (EXT1) EXT Control Terminal Input Connection Port Ext Output
Valid Timing Always-on Connection
Reference Level (Depending on the external device.)
Input Analog Gain
Input Digital Gain
EXT Output 1 (EXT1)
EXT Control Terminal Reference Level (Select a desired setting.)
Output Analog Gain
Output Digital Gain
Fade-out (Select a desired setting.)
Fade-in
Announce Tone Start Tone (Select a desired setting.)
End Tone
Announce Tone Volume
V/RoIP Control
Send Connect Success
Tone to Telephone
(Select a desired setting.)
Notice Tone Volume
Release Timer No Voice Release Timer 5 (seconds) (Select a desired setting.)
EXT Input 2 (EXT2) EXT Control Terminal Input Connection Port Emargency
Valid Timing Control Data Detection
EXT Control Terminal Input Type (Select a desired setting.)
Event ON Time
Event OFF Time
Control Input Detection (Depending on the external device.)
Control Input Pull-up Setting
Expansion Priority Control Priority Level Individual Calling Priority
Emergency Notice Emergency Notice Transceiver 1 (TRX1) Enable
EXT I/O 1 (EXT1) Enable
VE-PG3 (Area A)
5. Emergency Notice (continued)
1. Configuration
Access the VE-PG3 setting screen, and set the items as shown below.
(Continued on the next page.)
To Next Page
