Icom VE-PG3 - M EXT Voice Terminal

5
BRIDGE MODE SETTING SCREEN
5-99
8. [Port Settings] Menu (continued)
M EXT Voice Terminal
Set the audio output control details for the [EX1T]/[EXT2] port.
q Reference Level ………… Select the output level of A1/A2 terminal (Audio output), from "Speaker,"
"0dBs" and "–20dBs." (Default: –20dBs)
w Output Analog Gain ……… Set the analog signal input (A1/A2 terminal (Audio output)) gain. (Default: 0)
Range: "+15" to "–30"
e Output Digital Gain ……… Set the digital signal input (A1/A2 terminal (Audio output)) gain. (Default: 0)
Range: "+6" to "–12"
[Port Settings]–[EXT Output 1 (EXT1)/EXT Output 2 (EXT2)]
