Icom VE-PG3 - M Port Forwarding; M List of Port Forwarding Entries

5
BRIDGE MODE SETTING SCREEN
5-30
5. [Router] Menu (continued)
M Port Forwarding
The Port Forwarding function forwards the packets from a masquerade IP (Router Global IP) address to a private
IP address.
M List of Port Forwarding Entries
q WAN Port ………………… Select the mnemonic for the WAN port number.
Note: Select Custom to set the WAN port by number.
w LAN IP Address …………
Enter the private IP address.
e LAN Port ………………… Select Custom if you select the LAN port by the number.
r Protocol …………………… Select the protocol.
t Add ………………………… Click to submit the entry.
• Up to 32 tables can be submitted.
q Edit …………………………
Click to edit the entry.
• The entry contents are loaded to the Port Forwarding field above.
w Delete ………………………
Click to remove the entry.
[Router]–[NAT]
• This is an example.
