6
CONVERTER MODE SETTING SCREEN
6-136
M Abnormal Condition Monitoring
Configure the details to monitor the abnormal condition.
10. [Expansion] Menu (continued)
[Expansion]–[Abnormal Condition Monitoring]
• This is an example.
q LAN Port Downlink ……… Select “Enable” to automatically detect the communication error . When the
Ethernet cable disconnects from the VE-PG3’s [LAN] port, the [WAN] LED
lights Orange, and the error message is displayed on the “SYSLOG” screen
in the “Information” menu. (Default: Disable)
Control Output
Select "Enable" to output the error detect signal from the B1/B2 terminal
(+/–). (Default: Disable)
• Select "Relay circuit" in the Control Circuit] item on the [EXT Output] (1/2),
or [EXT I/O] (1/2) screen.
While the error detect signal is sent, the VE-PG3 cannot receive signals
from the external device that is connected to the B1/B2terminal (+/–).
To Next Page
