4. Making an emergency announcement (continued)
VE-PG3 (Area A)
Menu Item Setting Screen Setting Item Item Name Value
Operating Mode Operating Mode Operating Mode Operating Mode Converter
EXT I/O Port Mode EXT I/O Port Mode Separate
V/RoIP IP Line SIP Server IP Phone Number 99 (Extension Number set in the VE-PG3 in area B)
SIP Server Address 192.168.0.3 (IP address set in the VE-PG3 in area B)
SIP Service Domain
192.168.0.3 (Extension Domain set in the VE-PG3 in area B)
User ID 99 (Extension Number set in the VE-PG3 in area B)
Password (Password set in the VE-PG3 in area B)
List of SIP Server Entries Connection Status Connection successful
Extension
Connect
Extension Connect Extension Extension Number 301
(TRX1) Port Type Transceiver 1 (TRX1)
Default Call Destination No.
302 (From Radio 1 to EXT Output 1)
(EXT1) Extension Number 302
Port Type EXT Output 1 (EXT1)
(Emergency Notice) Extension Number 999
Port Type Emergency Notice
Incoming Call
V/RoIP Incoming Call Setting
Receive Port 99:999 (Emergency call No.)
Port Settings
Transceiver 1 (TRX1)
Transceiver Model: Transceiver Model IC-F5060/F6060 (default)
EXT Input 1 (EXT1) EXT Control Terminal Input Connection Port Emergency
Valid Timing Control Data Detect
Power for the Microphone
Enable
Reference Level (Depending on the external device)
Input Analog Gain
Input Digital Gain
EXT Output 1 (EXT1)
EXT Control Terminal Reference Level (Depending on the external device)
Output Analog Gain
Output Digital Gain
Fade-out (Select a desired setting)
Fade-in
Announce Tone Start Tone (Select a desired setting)
End Tone
Tone Level
V/RoIP Control
Send Connect Success
Tone to Telephone
(Select a desired setting)
Notice Tone Volume
Release Timer No Voice Release Timer 5 (seconds) (Select a desired setting)
Expansion Emergency Notice Emergency Notice Transceiver 1 (TRX1) Enable
EXT Output 1 (EXT1) Enable
1. Configuration
Access the VE-PG3 setting screen and set the items as shown below.
(Continued on the next page.)
To Next Page
