Icom VE-PG3 - Operating in the NXDN Trunking Mode

3
CONVERTER MODE APPLICATION
3-27
6. Operating in the NXDN Trunking mode
The IC-FR5000 series repeaters can be connected to the VE-PG3 through an Ethernet cable (IP network) using
the UC-FR5000 network board.
• The optional CT-24 digital voice converter is required.
VE-PG3
(192.168.0.2)
[D-TRX1]
Extension No.
401
Extension No.
201
Prefix ID: 01
ID: 1
Prefix ID: 01
ID: 2
*001 01 0001
Prefix ID: 01
ID: 200
Radio A1
Radio A2
System master repeater
Site 1
Site 2
CT-24
[USB]
#001 01 1000
#123
IP
Network
An example of a digital radio network system
Special number description:
• Individual Call
• Group Call
• All Call
q Radio Call Prefix for D-TRX1 Individual Call
w Prefix ID
e ID
P
0
P
1
P
2
P
3
P
4
IP telephone
(KX-UT Series)
qwe
q Radio Call Prefix for D-TRX1 Group Call
w Prefix ID
e ID
qwe
Special Number (Assigned as All Call)
VE-PG3
(192.168.0.3)
Repeater A
CT-24
P
0
P
1
P
2
P
3
P
4
1. UC-FR5000 configuration
Access the UC-FR5000 setting screen, and set the items as shown below.
Note: Since the VE-PG3 can accept up to
two CT-24’s, only two digital communication
lines are available at a time, even when three
D-TRX ports are connected to the network.
192.168.0.2
