Icom VE-PG3 - Configuration

3
CONVERTER MODE APPLICATION
3-6
2. Using an in-house sound system (continued)
VE-PG3 (Area A)
Menu Item Setting Screen Setting Item Item Name Value
Operating Mode Operating Mode Operating Mode Operating Mode Converter
EXT I/O Port Mode EXT I/O Port Mode Separate
V/RoIP IP Line SIP Server IP Phone Number 32 (Extension Number set in the VE-PG3 in area B)
SIP Server Address 192.168.0.3 (IP address set in the VE-PG3 in area B)
SIP Service Domain
192.168.0.3 (Extension Domain set in the VE-PG3 in area B)
User ID 32 (Extension Number set in the VE-PG3 in area B)
Password (Any) (Password set in the VE-PG3 in area B)
List of SIP Server Entries Connection Status Connection successful
Extension
Connect
Extension connect Extension Extension Number 301 (Transceiver1) 302 (EXT Output1)
Port Type Transceiver 1 (TRX1) EXT Output 1 (EXT1)
Default Call
Destination No.
302 –
Incoming Call
V/RoIP Incoming
Call Setting
Receive Port – 32:302 (EXT1)
Port Settings
Transceiver 1 (TRX1) Transceiver Model Transceiver Model IC-F5060/F6060 (default)
EXT Input 1 (EXT1) EXT Control Terminal Input Connection Port EXT Output
Valid Timing Always-on Connection
Reference Level (Depending on the external device)
Input Analog Gain
Input Digital Gain
EXT Output 1 (EXT1) EXT Control Terminal Reference Level (Depending on the external device)
Output Analog Gain
Output Digital Gain
Fade-out (Depending on the situation)
Fade-in
Announce Tone Start Tone (Depending on the situation)
End Tone
Tone Level
V/RoIP Control
Send Connect Success
Tone to Telephone
(Depending on the situation)
Notice Tone Volume
Release Timer No Voice Release Timer 5 (seconds) (Depending on the situation)
Expansion Priority Control Priority Level Individual Calling Priority
1. Configuration
Access the VE-PG3 setting screen, and set the items as shown below.
(Continued on the next page.)
