Icom VE-PG3 - M Transceiver Control

6
CONVERTER MODE SETTING SCREEN
6-72
9. [Port Settings] Menu (continued)
M Transceiver Control
Configure the details for [TRX1]/[TRX2] port.
q Priority Receive Mode … … Select “Enable” to restrict transmission while receiving an RF signal, even if
the transceiver detects audio signal from the SIP phone. (Default: Disable)
• When “Enable” is selected, the transceiver transmits only when receiving no
RF signal.
w PTT Cancel Mode ……… Select “Enable” to abort the calling to an IP phone when a transmit request is
detected. (Default: Disable)
e Call Back RX to TX ……… Select “Enable” to mix the audio from the repeater with the audio from the
telephone. (Default: Disable)
Note: When “Enable” is selected, select “Disable” in [Priority Receive].
r TX Volume ……………… Adjust the VE-PG3’s transmitting audio level that is sent to the connected
transceiver between “+6” and “–12” (dB). (Default: 0)
[Port Settings]–[Transceiver 1 (TRX1)/[Transceiver 2 (TRX2)]
* Appears only when “DTMF” is selected in [PTT Control Type from the Telephone].
** Appears only when “IC-FR5000/FR6000” or “General” is selected in [Transceiver Model].
*
*
!5
!6
**
An example of communication with the Call Back RX to TX function
Analog Telephone
PSTN
P
0
P
1
P
2
P
3
P
4
[TRX1]
“1, 2, 3”
“1, 2, 3”
“1, 2, 3”
“1, 2, 3”
“4, 5, 6”
+ “4, 5, 6”
“1, 2, 3”
+
“4, 5, 6”
[LINE1/2]
VE-PG3
Repeater
Radio A1
Radio A2
