8
FOR YOUR INFORMATION
8-6
M General
Power supply: DC12 V ±10% [Polarity ]
16W maximum (with the supplied AC adaptor)
Usable condition: Temperature 0 to 40°C, +32 to +104°F, Humidity 5–95% (At no condensation)
Dimension: Approximately 232 (W) × 38 (H) × 168 (D) mm, 9.1 (W) × 1.5 (H) × 6.6 (D) in
(objections not included)
Weight: Approximately 800 g, 28.2 oz (without the supplied accessory not included)
Regulatory Compliance: FCC (Part 15 Class B/Part 68)
TIA-968-B
ICES-003
ICCS-03
CE Mark
ETSI ES 203 021
ETSI EG 201 121 (Advisory Note)
Resolution 442
Resolution 473
Resolution 512
Resolution 529
ETSI TS 102 027-2 V4.1.1 (2006-07)
ITU-T G.711
Interface: LEDs
(PWR/MSG, WAN, V/RoIP, D-TRX, TRX(1/2), EXT(1/2)), Buttons (UPDATE, INIT)
[USB] ports (USB2.0)×2
M Communication Interfaces
[WAN] port: [WAN] port (RJ-45 type)×1 (Auto MDI/MDI-X)
• Based on IEEE802.3/10BASE-T
• Based on IEEE802.3u/100BASE-TX
[LAN] port: [LAN] port (RJ-45 type)×1 (Auto MDI/MDI-X)
• Based on IEEE802.3/10BASE-T
• Based on IEEE802.3u/100BASE-TX
[TRX] (1/2) port: Analog audio/Transmit control
2.54 mm (0.1 in) pitch quick connector (4 terminals ×3)×2
[EXT] (1/2) port: Audio input
–10 dBs/–40 dBs selectable Input impedance Approximately 10 k
unbalance
Audio output 0 dBs/–20 dBs selectable 600
load unbalance/8
1 W speaker
Control input Low voltage contacts (DC3.3 V/ 1 mA)/ Voltage input (3–16 V)
Control output No voltage contacts (30 V/ 500 mA)/Open collector (3–16 V 10 mA)
Connectors 2.54 mm (0.1 in) pitch quick connector (4 terminals ×3)×2
[LINE] port: RJ-11 ×2
[PHONE] port: RJ-11 ×1
Communication rate: [WAN] port 10/100 Mbps (Automatic switching/Full duplex)
[LAN] port 10/100 Mbps (Automatic switching/Full duplex)
Relay protocol: Only IPv4 for routing
Signaling protocol: SIP
Codec: G.711u, AMBE+2
4. Specifications
NOTE: All specifications are the subject to change without notice.
