CONVERTER MODE APPLICATION
3-32
7. Connecting to the Bridge mode's VE-PG3
VE-PG3 (Area C)
Menu Item Setting Screen Setting Item Item Name Value
Operating Mode Operating Mode Operating Mode Operating Mode Bridge
IP Communication Mode Transceiver 1 (TRX1) Multicast (default)
Transceiver 2 (TRX2) Multicast (default)
Bridge Connection Bridge Connection Point Bridge Connection Point Port Type Transceiver 1 (TRX1)/
Transceiver 2 (TRX2)
The List of Bridge Connection Point Entries Connection Status During Transmit
Port Settings Transceiver 1 (TRX1) Transceiver Model Transceiver Model IC-F5060/F6060 (default)
Transceiver 2 (TRX2) Transceiver Model Transceiver Model IC-F5060/F6060 (default)
1. Configuration (continued)
VE-PG3 (Area B)
Menu Item Setting Screen Setting Item Item Name Value
Operating Mode Operating Mode Operating Mode Operating Mode Converter
V/RoIP VoIP Phone Book List of VoIP Phone Book Entries Extension Number 31, 51
Extension Connect Extension Extension Extension Number 31
Port Type SIP Phone (Automatic Detection)
Password (Any)
MAC Address
(MAC address of the KX-UT series IP phone in area B)
Extension Extension Extension Number 51
Port Type SIP Phone (Automatic Detection)
Password (Enter a password)
MAC Address (MAC address of the KX-UT series IP phone in area B)
Extension Extension Extension Number 401
Port Type: SIP Phone(KX-UT Series)
Password: (Enter a password)
MAC Address (MAC address of the KX-UT series IP phone in area B)
Incoming Call V/RoIP Incoming Call Setting Receive Port 401 (Receive port of VE-PG3 in area A)
