5
BRIDGE MODE SETTING SCREEN
5-8
3. [Information] Menu
M SYSLOG
Displays the log information. The latest 500 log entries are displayed.
(This is an example.)
[Information]–[SYSLOG]
q Severity …………………… Select the log information to display.
• Enter a check mark to display the log entries.
• Remove the check mark and click <Refresh> to hide the entries.
(Default: M DEBUG M INFO M NOTICE)
Note: The selection is not stored, and reset when you leave this screen.
w <Refresh> ………………… Click to refresh the log screen.
e <Clear> …………………… Click to delete all log entries.
Note: All log entries are also deleted when the VE-PG3 is turned OFF or ini-
tialized.
r <Save> …………………… Click to save the log to a PC with a text file (extension: “txt”).
• Click this button, and then select a folder to save the file.
