Icom VE-PG3 - M Bridge Connection (1 to 4)

6
CONVERTER MODE SETTING SCREEN
6-111
9. [Port Settings] Menu (continued)
M Bridge Connection (1 to 4)
Configure the Bridge connection.
q Destination IP Address …
The input content differs according to the contents set in [Bridge 1] to [Bridge 4] .
(Default: 239.255.255.1)
• When "Multicast" is selected:
Enter the destination VE-PG3’s Destination IP address.
Range: "224.0.0.0" to "239.255.255.255" (class D)
• When "Unicast" is selected: (Default: None)
Enter the destination VE-PG3’s IP address or domain name. (Up to 63
characters)
[Port Settings]–[Bridge 1–Bridge 4]
IP Communication Mode: Unicast
IP Communication Mode: Multicast
