Icom VE-PG3 - Operation

2
BRIDGE MODE APPLICATION
2-7
2. Operation in the Unicast mode (continued)
• All radios in the area must have same setting.
3. Operation
• Radio A1 and B1 can normally communicate as if they are directly communicating in the simplex mode.
Area AArea B
An example of communication the Unicast mode
Radio A
Radio B
Radio A1 Radio B1
VE-PG3
(192.168.0.3)
VE-PG3
(192.168.0.2)
[TRX1]
[LAN][LAN]
[TRX1]
