7
MAINTENANCE
7-11
7. About the Automatic Restore function (continued)
Settings files management
The settings files and firmware files can be saved in the different folders in a USB flash drive.
• The folder name must be the WAN side MAC address.
Example: WAN side MAC address is 0090C7000001
Inserting the USB flash drive, which contains the files shown below, to the VE-PG3 (MAC address: 0090C7000001),
the backup setting file is automatically created in the “0090C7000001” folder.
The settings files and firmware files are load from the “0090C7000001” folder into the VE-PG3 (MAC address:
0090C7000001).
• Settings file or firmware file in other than the “0090C7000001” folder is ignored.
Inserting the USB flash drive, which contains the files shown below, to the VE-PG3 (MAC address: 0090C7000002),
because there is no folder named “0090C7000002” (VE-PG3’s WAN side MAC name), the backup setting file is auto-
matically created in the root directory of the USB flash drive.
The settings files and firmware files are load from the root directory into the VE-PG3 (MAC address: 0090C7000002).
Backup file’s modified
date is not displayed.
Settings files and
firmware for except
“0090C7000001.”
( I f t h e r e i s t h e
“00 9 0C7 0 000 02”
f o l d e r , t h e y a r e
stored in the folder.)
To Next Page
