Datasheet 243
Functional Description
5.24.1.2 Descriptor Mode
Descriptor Mode is required for all SKUs of the PCH. It enables many new features of
the chipset:
• Integrated Gigabit Ethernet and Host processor for Gigabit Ethernet Software
•Intel
Active Management Technology
•Intel
Management Engine Firmware
• PCI Express* root port configuration
• Supports up to two SPI components using two separate chip select pins
• Hardware enforced security restricting master accesses to different regions
• Chipset Soft Strap regions provides the ability to use Flash NVM as an alternative to
hardware pull-up/pull-down resistors for the PCH and processor
• Supports the SPI Fast Read instruction and frequencies of up to 50 MHz
• Support Single Input, Dual Output Fast read
• Uses standardized Flash Instruction Set
5.24.1.2.1 SPI Flash Regions
In Descriptor Mode the Flash is divided into five separate regions:
Only three masters can access the four regions: Host processor running BIOS code,
Integrated Gigabit Ethernet and Host processor running Gigabit Ethernet Software, and
Management Engine. The only required region is Region 0, the Flash Descriptor. Region
0 must be located in the first sector of Device 0 (Offset 0).
Region Content
0 Flash Descriptor
1BIOS
2 Management Engine
3Gigabit Ethernet
4Platform Data
