284 Datasheet
Ballout Definition
Table 6-2. Mobile PCH Ballout By Signal Name
Mobile PCH Ball
Name
Ball #
A20GATE P4
ACPRESENT /
GPIO31
H20
APWROK L10
BATLOW# / GPIO72 E10
BMBUSY# / GPIO0 T7
CL_CLK1 M7
CL_DATA1 T11
CL_RST1# P10
CLKIN_DMI_N BF18
CLKIN_DMI_P BE18
CLKIN_DOT_96N G24
CLKIN_DOT_96P E24
CLKIN_GND1_N BJ30
CLKIN_GND1_P BG30
CLKIN_PCILOOPBAC
K
H45
CLKIN_SATA_N AK7
CLKIN_SATA_P AK5
CLKOUT_DMI_N AV22
CLKOUT_DMI_P AU22
CLKOUT_DP_N AM12
CLKOUT_DP_P AM13
CLKOUT_ITPXDP_N AK14
CLKOUT_ITPXDP_P AK13
CLKOUT_PCI0 H49
CLKOUT_PCI1 H43
CLKOUT_PCI2 J48
CLKOUT_PCI3 K42
CLKOUT_PCI4 H40
CLKOUT_PCIE0N Y40
CLKOUT_PCIE0P Y39
CLKOUT_PCIE1N AB49
CLKOUT_PCIE1P AB47
CLKOUT_PCIE2N AA48
CLKOUT_PCIE2P AA47
CLKOUT_PCIE3N Y37
CLKOUT_PCIE3P Y36
CLKOUT_PCIE4N Y43
CLKOUT_PCIE4P Y45
CLKOUT_PCIE5N V45
CLKOUT_PCIE5P V46
CLKOUT_PCIE6N V40
CLKOUT_PCIE6P V42
CLKOUT_PCIE7N V38
CLKOUT_PCIE7P V37
CLKOUT_PEG_A_N AB37
CLKOUT_PEG_A_P AB38
CLKOUT_PEG_B_N AB42
CLKOUT_PEG_B_P AB40
CLKOUTFLEX0 /
GPIO64
K43
CLKOUTFLEX1 /
GPIO65
F47
CLKOUTFLEX2 /
GPIO66
H47
CLKOUTFLEX3 /
GPIO67
K49
CLKRUN# / GPIO32 N3
CRT_BLUE N48
CRT_DDC_CLK T39
CRT_DDC_DATA M40
CRT_GREEN P49
CRT_HSYNC M47
CRT_IRTN T42
CRT_RED T49
CRT_VSYNC M49
DAC_IREF T43
DcpRTC N16
DcpSST V16
DcpSus AL24
DcpSus T17
DcpSus V19
DcpSus AN23
DcpSusByp V12
DDPB_0N AV42
DDPB_0P AV40
DDPB_1N AV45
DDPB_1P AV46
DDPB_2N AU48
DDPB_2P AU47
DDPB_3N AV47
DDPB_3P AV49
DDPB_AUXN AT49
DDPB_AUXP AT47
DDPB_HPD AT40
DDPC_0N AY47
DDPC_0P AY49
Mobile PCH Ball
Name
Ball #
DDPC_1N AY43
DDPC_1P AY45
DDPC_2N BA47
DDPC_2P BA48
DDPC_3N BB47
DDPC_3P BB49
DDPC_AUXN AP47
DDPC_AUXP AP49
DDPC_CTRLCLK P46
DDPC_CTRLDATA P42
DDPC_HPD AT38
DDPD_0N BB43
DDPD_0P BB45
DDPD_1N BF44
DDPD_1P BE44
DDPD_2N BF42
DDPD_2P BE42
DDPD_3N BJ42
DDPD_3P BG42
DDPD_AUXN AT45
DDPD_AUXP AT43
DDPD_CTRLCLK M43
DDPD_CTRLDATA M36
DDPD_HPD BH41
DMI_IRCOMP BG25
DMI_ZCOMP BJ24
DMI0RXN BC24
DMI0RXP BE24
DMI0TXN AW24
DMI0TXP AY24
DMI1RXN BE20
DMI1RXP BC20
DMI1TXN AW20
DMI1TXP AY20
DMI2RBIAS BH21
DMI2RXN BG18
DMI2RXP BJ18
DMI2TXN BB18
DMI2TXP AY18
DMI3RXN BG20
DMI3RXP BJ20
DMI3TXN AV18
DMI3TXP AU18
DPWROK E22
Mobile PCH Ball
Name
Ball #
